Mounting and Installation Part A VC 6000
TM
Compact monitor
© VC 6000
TM
Compact monitor Juni 2014 C100575.002 Introduction Vers.10 - 33 -
9.5.3.5 Buffered outputs
The buffered outputs are at BNC sockets, located on each sensor input
module.
9.5.3.6 Reset input
CAUTION!
The peripheral components connection variants shown here do not
claim to be comprehensive or complete.
Please also consult the technical documentation of the peripheral
equipment you wish to connect to the VIBROCONTROL 6000 Compact monitor!
