1-channel input module for acceleration sensors Part B VC-6000
TM
Compact monitor
© VC-6000
TM
Compact monitor Nov, 2014 C100584.002 Module Vers. 08 - 21 -
2.3.2 Equipment and signalling
Possible socket positions on the Base Module:
X1_M X2_M X3_M
Connection plugs on the Base Module (dependent on the selected
socket position): X1 X2 X3
A-TIM (-24 V) Pin layout connections X1/X2/X3
PIN Signal Explanation
1 0 V Sensor power supply
2 -24 V Sensor power supply
3 COM Sensor signal reference potential
4 SIG Sensor signal
5 Not connected
6 0 V 0 V
A-TIM (CCS) Pin layout connections X1/X2/X3
PIN Signal Explanation
1 0 V OUT
2 -24 V OUT
3 COM
(
-) Sensor signal reference potential
4 SIG
(
+) Sensor signal and 8 mA constant
current
5
6 0 V OUT
