Operating Instructions ACTIVE 06/07212
212 Operating Instructions ACTIVE 06/07
Search Run
No. Description Unit Setting range Chapter
645 Operation mode - Selection 11.5
646 Brak. Time after Search Run s 0.0 ... 200.0 11.5
647 Current / Rated Motor Current % 1.00 ... 100.00 11.5
648 Amplification - 0.00 ... 10.00 11.5
649 Integral Time ms 0 ... 1000 11.5
Auto Start
651 Operation mode - Selection 11.4
Slip compensation
660 Operation mode - Selection 16.4.1
661 Amplification % 0.0 ... 300.0 16.4.1
662 Max. Slip Ramp Hz/s 0.01 ... 650.00 16.4.1
663 Minimum Frequency Hz 0.01 ... 999.99 16.4.1
Voltage controller
670 Operation mode - Selection 16.2
671 Mains Failure Threshold V -200.0 ... –50.0 16.2
672 Reference Mains Support Value V -200.0 ... –10.0 16.2
673 Mains Support Deceleration Hz/s 0.01 ... 9999.99 16.2
674 Acceleration on Mains Resumption Hz/s 0.00 ... 9999.99 16.2
675 Shutdown Threshold Hz 0.00 ... 999.99 16.2
676 Reference Shutdown Value V U
dmin
+25 ... U
dmax
-25 16.2
677 Amplification - 0.00 ... 30.00 16.2
678 Integral Time ms 0 ... 10000 16.2
680 Reference DC-Link Limitation V U
dmin
+25 ... U
dmax
-25 16.2
681 Max. Frequency Rise Hz 0.00 ... 999.99 16.2
683 Gen. Ref. Current Limit A
0.0 ... o
⋅ I
FIN
16.2
Current Controller
700 Amplification - 0.00 ... 2.00 16.5.1
701 Integral Time ms 0.00 ... 10.00 16.5.1
Further motor parameters
713 Magnetizing Current 50% Flux % 1 ... 50 9.2.3
714 Magnetizing Current 80% Flux % 1 ... 80 9.2.3
715 Magnetizing Current 110% Flux % 110 ... 197 9.2.3
716 Rated Magnetizing Current A
0.01
⋅I
FIN
... o⋅I
FIN
9.2.3
Field Controller
717 Reference Flux % 0.01 ... 300.00 16.5.5
Further motor parameters
718 Rated Slip Correction Factor % 0.01 ... 300.00 9.2.4
Frequency Limits
719 Slip Frequency % 0 ... 10000 13.1
Speed controller
720 Operation mode - Selection 16.5.3
721 Amplification 1 - 0.00 ... 200.00 16.5.3
722 Integral Time 1 ms 0 ... 60000 16.5.3
723 Amplification 2 - 0.00 ... 200.00 16.5.3
724 Integral Time 2 ms 0 ... 60000 16.5.3
Acceleration Pre-Control
725 Operation mode - Selection 16.5.4
726 Minimum Acceleration Hz/s 0.1 ... 6500.0 16.5.4
727 Mech. Time Constant ms 1 ... 60000 16.5.4
