BONFIGLIOLI Act 201 User Manual

Operating Instructions ACTIVE06/07 213
06/07 Operating Instructions ACTIVE 213
Speed controller
No. Description Unit Setting range Chapter
728 Current Limit A
0.0 ... o
⋅ I
FIN
16.5.3.1
729 Current Limit Generator Operation A
-0.1 ... o
⋅ I
FIN
16.5.3.1
730 Torque Limit % 0.00 ... 650.00 16.5.3.1
731 Torque Limit Generator Operation % 0.00 ... 650.00 16.5.3.1
732 P-Comp. Torque Upper Limit % 0.00 ... 650.00 16.5.3.1
733 P-Comp. Torque Lower Limit % 0.00 ... 650.00 16.5.3.1
Speed controller
734 Isq Limit Source Motor Operation - Selection 16.5.3.2
735 Isq Limit Source Generator Op. - Selection 16.5.3.2
736 Torque Limit Source Motor Op. - Selection 16.5.3.2
737 Torque Limit Source Gen. Op. - Selection 16.5.3.2
738 Speed Control Switch-Over Limit Hz 0.00 ... 999.99 16.5.3
739 Power Limit kW
0.00 ... 2
⋅o⋅P
FIN
16.5.3.1
740 Power Limit Generator Operation kW
0.00 ... 2
⋅o⋅P
FIN
16.5.3.1
Field Controller
741 Amplification - 0.0 ... 100.0 16.5.5
742 Integral Time ms 0.0 ... 1000.0 16.5.5
743 Ref. Isd Upper Limit A
0.1
⋅I
FIN
... o⋅I
FIN
16.5.5.1
744 Ref. Isd Lower Limit A -I
FIN
... I
FIN
16.5.5.1
Speed controller
748 Backlash Damping % 0 ... 300 16.5.3
Modulation Controller
750 Reference Modulation % 3.00 ... 105.00 16.5.6
752 Integral Time ms 0.0 ... 1000.00 16.5.6
753 Operation mode - Selection 16.5.6
755 Reference Imr Lower Limit A
0.01
⋅I
FIN
... o⋅I
FIN
16.5.6.1
756 Control Deviation Limitation % 0.00 ... 100.00 16.5.6.1
Encoder Monitoring
760 Operation mode - Selection 17.7.3
761 Timeout: Signal Fault ms 0 ... 65000 17.7.3
762 Timeout: Channel fault ms 0 ... 65000 17.7.3
763 Timeout: Direction fault ms 0 ... 65000 17.7.3
Torque Controller
767 Frequency Upper Limit Hz -999.99 ... 999.99 16.5.2
768 Frequency Lower Limit Hz -999.99 ... 999.99 16.5.2
769 Frequency Upper Limit Source - Selection 16.5.2.1
770 Frequency Lower Limit Source - Selection 16.5.2.1
Starting Behavior
780 Max. Flux-Formation Time ms 1 ... 10000 11.1.2
781 Current during Flux Formation A
0.1
⋅I
FIN
... o⋅I
FIN
11.1.2
