36 | FSA 050 | Technical dataen
Resistance measurement
Function Specification
EN 61557
operating range
0.01 kΩ to 1000 kΩ
(0 to 1 MΩ on analog scale)
Accuracy ±5% ±2 positions
Voltage in open
circuit
5 V ±1 V
Short-circuit
current
20 μA ±5 μA
Voltage measurement
R 0 to 600 V DC ± 2 % ± 2 positions
R 10 mV to 600 V TRMS sinusoidal (40–400 Hz) ±2 % ±2
positions
R 0 to 1000 V on the analog scale
R Non-specified input level 0 – 10 mV (40 – 400 Hz)
R Additional specifications apply to non-sinusoidal
curves:
$ ±3% ±2 positions / 101 mV – 600 V TRMS and
$ ±8% ±2 positions / 10 mV – 100 mV TRMS
Standard voltmeter
R Operates at >25 V AC or DC in any range except OFF
R Frequency:
40 – 450 Hz (40 Hz – 99.9 Hz) ±0.5% ±1 position
(100 Hz to 450 Hz)
Capacitance measurement
Function Specification
Measuring range 100 pF to 10 μF
Accuracy ±5.0 % ±2 positions
Storage of measurement results
Function Specification
Capacity > 1000 test results
Download Bluetooth wireless
Bluetooth class I/II
Workshop environment
in the open space:
Class 1
Class 2
30 m
5 m
i The Bluetooth class can only be set using the
CompacSoft[plus] software.
Power supply
Five 1.5 V cells of type IEC LR6 (AA, MN1500, HP7, AM3
R6HP) alkaline or rechargeable NiMH.
Battery service life
2200 insulation tests with a duty cycle of 5sON and
55s OFF at 1000 V and 1 MΩ
Dimensions
Function Specification
Tester 220 x 92 x 50 mm (8.66 x 3.63 x 1.97 inch)
Tester + case 456 x 178 x 89 mm (18 x 7 x 3.5 inch)
Weight
Function Specification
FSA 050 800 g
FSA 050 + case 1.75 kg
Fuse
R Only use 500mA (FF), 1000 V, 32 x 6 mm ceramic
fuse with a high blow capacity of at least HBC 50 kA.
Use is not to be made of glass fuses.
Temperature coefficient
R <0.1 % per °C up to 1 GΩ
R <0.1 % per °C per GΩ above 1 GΩ
Ambient conditions
Function Specification
Operating range -20 °C to 55 °C
Operating humidity 95% RH 0 °C to 35 °C,
70% RH 35 °C to 55 °C
Storage temperature range -30 °C to 80 °C
Calibration temperature 20 °C
Maximum usage altitude 2000 m
Protection against dust
and water
IP54
RED (Radio Equipment Directive)
Wireless link Frequency band Maximum radiated
transmitter power
output
Bluetooth 2,4 GHz 19,9 dBm
