Decommissioning | FSA 050 | 35 en
7. Decommissioning
7.1 Change of location
¶ If the FSA 050 is passed on, all the documentation
included in the scope of delivery must be handed over
together with the unit.
¶ The FSA 050 is only ever to be transported in the
original or equivalent packaging.
¶ Unplug the electrical connection.
¶ Heed the notes on initial commissioning.
7.2 Disposal and scrapping
FSA 050, accessories and packaging should
be sorted for environmental-friendly recycling.
¶ Do not dispose FSA 050 into household
waste.
Only for EC countries:
The FSA 050 is subject to the European
directive 2012/19/EC (WEEE).
Dispose of used electrical and electronic
devices, including cables, accessories and
batteries, separately from household waste.
¶ Make use of the local return and collection
systems for disposal.
¶ Proper disposal of FSA 050 prevents
environmental pollution and possible health
hazards.
8. Technical data
i All the values given are referenced to a temperature
of 20 °C.
Insulation analysis
i The specifications only apply in conjunction with
the remote sensor and the measurement leads
contained in the scope of delivery.
Range Accuracy
1000 V 200 GΩ ±3% ±2 positions ±0.2 % per GΩ
500 V 100 GΩ ±3 % ±2 positions ±0.4 % per GΩ
250 V 50 GΩ ±3 % ±2 positions ±0.8 % per GΩ
100 V 20 GΩ ±3 % ±2 positions ±2.0 % per GΩ
50 V 10 GΩ ±3 % ±2 positions ±4.0 % per GΩ
Function Specification
Analog
display range
1 GΩ for full scale deflection
Short-circuit
current
2 mA 0% – 50%
Terminal
voltage
0% – 20 % ±1 V (Ii <1 mA)
Test current level
under load
1 mA for minimum insulation continuity
value according to specification as per
BS7671, HD384 and IEC364, EN61152-2,
2 mA maximum
EN 61557
operating range
0.10 MΩ to 1.00 GΩ
Leakage current
measurement
range
10 μA to 2000 μA
Leakage current 10% ±3 positions
Voltage display 3% ±3 positions ±0.5% of rated voltage
Polarisation
index (PI)
Ratio of 10 minutes to 1 minute
Dielectric
absorption ratio
(DAR)
Ratio of 60 s to 30 s
Continuity measurement
Function Specification
EN61557
operating range
0.01 Ω to 99.9 Ω
(0 to 100 Ω on analog scale)
Accuracy ±2% ±2 positions (0 to 100 Ω)
Voltage in
open circuit:
5 V ± 1 V
Test current 205 mA (±5 mA) (0.01 Ω to 9.99 Ω)
20 mA (±1 mA) (10.0 Ω to 99.9 Ω)
Zero adjustment
at remote
sensor tips
Usually 0.10 Ω
Zero adjustment
of line resistance
Up to 9.99 Ω
Buzzer Variable limit: 1 Ω, 2 Ω, 5 Ω, 10 Ω, 20 Ω
