PIN To Change Area
Setting this option will prevent a user from switching
between different areas on the keypad unless they enter
a valid user PIN.
When this option is not set, users will be able to
change the keypad view to all other areas in the system
regardless of whether or not they have access to those
areas.
Home Area Only
Setting this option will force the keypad to display only
it’s assigned home area information. Therefore a user
cannot toggle (or move) the keypad display to show that
of a different area when the system has been partitioned.
Devices > Keypads & Readers >
Home Area
MENU 6-1-3
0 1
00 - No Area
01 - Security System 05 - Area 5 Name
02 - Area 2 Name 06 - Area 6 Name
03 - Area 3 Name 07 - Area 7 Name
04 - Area 4 Name 08 - Area 8 Name
This menu allows you to assign each keypad or LAN reader
to a default home area (Area 1 to 8). Only 1 home area can
be programmed for each keypad or LAN reader.
If a user toggles the keypad display to view a different
area, the keypad will automatically timeout and move
back to the home area if no key is pressed for a period of
60 seconds.
To prevent users from viewing areas which they do
not have access to, you will need to enable the PIN
To Change Area option. Setting this option will set
the system to request a user’s PIN before allowing
them to view another area. The system will only
allow a user to view the areas they have access to.
See MENU 6-1-4 — Keypad General Options.
1) Press [MENU] + [6] + [1] + [3] and use the up and
down arrows to highlight the keypad in the list
then press [OK]. Use the up and down arrow keys
to select the Home Area required then press [OK] to
save and exit or press [MENU] to exit without
saving.
Home Area Kp1
01 - Security System
Press 0-9 OK to SAVE
Each keypad must be set to a unique address via the
DIP switches on the keypad and each keypad must
have a home area programmed to operate correctly.
Area 1 is the default home area for all keypads.
Devices > Keypads & Readers >
General Options
MENU 6-1-4
1 Enable Rear Tamper N
2 Report Temperature Y
3 Installer PIN Allowed Y
4 Show Alarm When Armed Y
5 Reader Area Control Y
6 Reader Badging N
7 Enable Egress Input N
8 Log Egress Events N
The above options can be configured independantly for
each keypad fitted to the system.
1) Press [MENU] + [6] + [1] + [4] and use the up and
down arrows to highlight the keypad in the list
then press [OK].
Enable Rear Tamper
Report Temperature
Installer PIN Allowed
Press OK ON OFF MENU
2) Use the up and down arrow keys to highlight the
option then press the [ON] key to enable or the
[OFF] key to disable.
3) Repeat Step 2 until all options are programmed as
required, then press [OK] to save and exit or press
[MENU] to exit without saving.
Enable Rear Tamper
This option allows the tamper circuit located on the back
of the LAN device to function. As soon as the LAN device
has been removed from the wall, the control panel will
register an alarm event.
For this option to work, the keypad model being used
must have the on-board tamper switch fitted.
Report Temperature
This option allows the control panel to report
temperature high and low alarm reports when the
temperature at the LAN device falls below or increases
outside the global temperature settings in MENU 7-7-3.
Installer PIN Allowed
This option allows the installer to access to the system
menus or to turn the area (or system) on or off at LAN
device.
Show Alarm When Armed
This option allows the keypad to display which zone
registered an alarm. If multiple zones have registered an
alarm, the keypad will scroll each zone one at a time.
If the option is programmed, the keypad will display as
below:
To Next Page
