Solution 6000-IP
Installation Manual Output Programming
8-16
Bosch Security Systems 10/22 BLCC615I
Delete RF Device
This menu allows the installer to delete a relay on the
RF160 module. This menu does not delete the actual
output configuration set at the control panel.
Outputs > RF Output
Delete RF Device
MENU 4-3-1
This menu allows the installer to delete relay 1 and/or
relay 2 of the RF160 module.
1) Press [MENU] + [4] + [3] + [1] and use the up and
down arrows to highlight the output in the list,
then press [OK].
Op1 External Siren
Op2 Strobe Light
Op3 Smoke Sensor PWR
Press OK or MENU
2) The keypad will display the current RF160 ID.
Delete Device ID Op6
Garage Door
0F9105130 Relay1
Press OK or MENU
3) Press [OK] to delete and exit or press [MENU] to exit
without saving.
Relay 1
Relay 2
Exit
Press OK or MENU
Defaulting The RF160 Module
This function allows an installer to delete parameters
stored in the RF160 module including the RF Site ID.
You will need to do this if you are relocating the unit to
another system.
To default, first power the unit, then press and hold both
relay buttons down until the Green RF and Red PGM indi-
cators flash rapidly, then release the buttons and the unit
will have defaulted. (Approximately 10 seconds).
Test RF Device
Outputs > RF Output
Test RF Device
MENU 4-3-2
This menu allows the installer to test RF160 module
output for signal level.
1) Press [MENU] + [4] + [3] + [2] and use the up and
down arrows to highlight the output in the list,
then press [OK].
Op1 External Siren
Op2 Strobe Light
Op3 Smoke Sensor PWR
Press OK or MENU
2) The keypad will display the current RF160 ID.
Op6 Garage Door
Waiting for Trigger!
Press OK or MENU
3) Press and hold both relay buttons on the RF160
module to transmit a packet (signal).
Op6 Garage Door
Rx3 Packets=001 v2.02
Signal Good <247>
Press OK or MENU
4) Press [OK] or press [MENU] to exit.
The keypad will display the receiver address that received
the packet (signal) from the RF160, the packet count, the
firmware of the RF160 and the signal strength.
