Solution 6000-IP
Installation Manual Output Programming
8-14
Bosch Security Systems 10/22 BLCC615I
DOOR CONTROL
Outputs > Door Properties >
Door Name
-
MENU 4-2-0
D o o r 1 N a m e
This menu allows you to program the name for each
output. Door names can be up to 20 characters long.
1) Press [MENU] + [4] + [2] + [0] and use the up and
down arrows to highlight the door in the list then
press [OK]. Alternatively, you can enter the door
number directly and press [OK].
2) Use the arrow and number keys to move and
change text. When the door name is complete,
press [OK]. At any time you can press the [OFF] key
to clear the text from the current cursor position to
the end of the line.
Door Name Dr1
Door 1 Name
Press OK to SAVE
See Alpha Text Programming in Section 4 —
Programming Overview for further detail on entering
alpha text.
Outputs > Door Properties >
Unlock TimeZone
MENU 4-2-2
0 0
00 - Disabled
01 - 24 Hour TimeZone 09 - TimeZone 9 Name
02 - TimeZone 2 Name 10 - TimeZone 10 Name
03 - TimeZone 3 Name 11 - TimeZone 11 Name
04 - TimeZone 4 Name 12 - TimeZone 12 Name
05 - TimeZone 5 Name 13 - TimeZone 13 Name
06 - TimeZone 6 Name 14 - TimeZone 14 Name
07 - TimeZone 7 Name 15 - TimeZone 15 Name
08 - TimeZone 8 Name 16 - TimeZone 16 Name
The unlock timezone is used to control the output which
is assigned to operate the door lock. When the timezone
is true, the output assigned to the corresponding door will
be activated. Options are provided to stop the door from
automatically operating if an area is armed or no users on
site. The list of doors will appear, move the cursor over the
door you wish to select and press the OK key.
1) Enter [MENU] + [4] + [2] + [2]. The list of doors will
appear, move the cursor over the door you wish to
select and press the [OK] key.
Unlock TimeZone Dr1
00 - Disabled
Press 0-9 OK to SAVE
2) Use the arrow or number keys to select the time
zone that you want the door to follow, then press
[OK] to save and exit.
Outputs > Door Properties >
Door Options
MENU 4-2-3
1 Hold Off If Area Armed Y
2 Hold Off Auto Unlock N
3 Reserved N
4 Report Door Forced N
5 Alarm Door Forced N
6 Report DOTL N
7 Alarm On DOTL N
8 Lift Door N
1) Press [MENU] + [4] + [2] + [3] and select the door
you want to program from the list then press [OK].
Alternatively, you can directly enter the door
number then press [OK].
2) Use the up and down arrow keys to highlight the
option, then press the [ON] key to enable or the
[OFF] key to disable.
Hold O If Area Armed
Hold Off Auto Unlock
Reserved
Press OK ON OFF MENU
3) Repeat Step 2 until all options are programmed as
required, then press [OK] to save and exit or press
[MENU] to exit without saving.
Hold Off If Area Armed
This option when enabled and used in conjunction with
a timezone assigned under the door control menu will
stop the door from unlocking if the area behind the door
is armed. This is very useful in cases where the holiday
list may not have been kept up to date.
Hold Off Auto Unlock
Setting this option on a door will delay the automatic
unlocking at the set time, until a valid credential is
presented at a reader assigned to the door. Example: Dr1
is assigned to Tz2 (9am to 5pm) then 9am comes around
and the door does not open. When a valid user presents
their credential at 9.10am the door opens and stays held
open until 5pm.
Report Door Forced
Setting this option allows the control panel to report
door forced and door forced restore events. These
events follow the Access Route set in MENU 1-6-0. It will
also appear in the keypad display as an alarm condition
identifying the door 'ALARM Door 1 Name'.
To Next Page
