Solution 6000-IP
Installation Manual Programming Overview
4-6
Bosch Security Systems 10/22 BLCC615I
MENU REFERENCE TABLE
The control panel includes a simple text menu system which makes all levels of programming extremely easy. Once
a valid PIN has been entered followed by the MENU key, the system will automatically determine which menus and
options the PIN holder has access to and only those items will be displayed.
There are four basic grouping levels used. Throughout the manual, symbols have been placed near each menu option
so that you can easily relate the authority level which is required to access them.
A =
= All (No PIN Required)
U =
= User PIN Has Access
M =
= Master PIN Has Access
I =
= Installer PIN Has Access
The following table lists all programming menus and the authority level required to access them.
0 Commands 1 Access 2 Areas
UMI 2-0-1 Turn Area On/Off 1-0 Commands 2-0 Commands
UMI 2-0-2 Turn All Areas On MI 1-0-0 Erase User AUMI 2-0-0 Area Status
UMI 2-0-3 Turn All Areas Off UMI 2-0-1 Turn Area On/Off
UMI 2-0-4 Move To Area 1-1 PIN Codes UMI 2-0-2 Turn All Areas On
AUMI 2-0-5 Chime On/O UMI 1-1-0 Change Own PIN UMI 2-0-3 Turn All Areas Off
UMI 1-1-0 Change Own PIN MI 1-1-1 Change Other PIN UMI 2-0-4 Move To Area
AUMI 3-0-0 Zone Status MI 1-1-2 Add PIN AUMI 2-0-5 Chime On/O
AUMI 4-0-0 Output Status MI 1-1-3 Delete PIN MI 2-0-6 Chime Mode
UMI 4-0-1 Turn Output On/Off I 1-1-4 View PIN
MI 7-1-0 Set Date And Time 2-1 Area Properties
UMI 3-0-5 Smoke Sensor Reset 1-2 Token MI 2-1-0 Area Name
UMI 3-9-0 Walk Test All Zones MI 1-2-0 Add Token I 2-1-1 General Options
MI 4-9-0 External Siren Test MI 1-2-1 Delete Token I 2-1-2 Input Options
MI 4-9-1 Internal Siren Test MI 1-2-2 Token Status I 2-1-3 Output Options
MI 4-9-2 Strobe Test MI 1-2-3 Edit Token I 2-1-4 Reporting Options
UMI 7-9-1 Battery Test I 2-1-5 Strobe Trigger
I 7-0-8 Service Mode 1-3 RF Keyfob MI 2-1-6 Part Mode 1 Name
UMI About MI 1-3-0 Add Keyfob MI 2-1-7 Part Mode 2 Name
MI 1-3-1 Delete Keyfob MI 2-1-8 Auto Arming
I 1-3-2 Test Keyfob
2-2 Reporting
1-4 User Properties I 2-2-0 Account Dest 1
MI 1-4-0 User Name I 2-2-1 Account Dest 2
MI 1-4-1 Area Assignment I 2-2-2 Open Close Route
MI 1-4-2 User Options
MI 1-4-4 TimeZone Access 2-8 Timers
MI 1-4-5 Door Assignment MI 2-8-0 Exit Time
MI 1-4-6 User Expire Date MI 2-8-1 Entry Time 1
MI 2-8-2 Entry Time 2
1-5 Global Properties MI 2-8-3 Part Entry Time
I 1-5-0 PIN Length I 2-8-4 Auto Arm Pre Alert
I 1-5-1 PIN Retry Count I 2-8-6 Senior Watch Time
I 1-5-2 Installer PIN
2-9 Area Testing
1-6 Reporting I 2-9-0 Area Watch
I 1-6-0 Access Route I 2-9-1 User Test Interval
I 1-6-1 Access Options I 2-9-2 Service Interval
I 2-9-3 Test Options
1-8 Fingerprint
MI 1-8-0 Add Fingerprint
MI 1-8-1 Delete Fingerprint
MI 1-8-2 Fingerprint Status
Table 15: Menu Reference Table
