Solution 6000-IP
Installation Manual Comms Programming
9-5
Bosch Security Systems 10/22 BLCC615I
MYALARM
Comms > MyAlarm >
IP Address
MENU 5-5-0
1 Digits 12
0 0 0 0 0 0 0 0 0 0 0 0
This menu programs the 12 digit MyAlarm IP Address.
MENU 5-5-0 should be left at the factory default
settings unless you are advised otherwise by the
manufacturer.
1) Press [MENU] + [5] + [5] + [0]. Use the arrow keys to
select the IP address to program, then press the
[OK] key. The keypad will display the current IP
address.
Primary IP Address
000000000000
Press 0-9 OK to SAVE
2) Using the numeric keys, enter the IP address
required, then press [OK] to save and exit, or press
[MENU] to exit without saving.
Comms > MyAlarm >
IP Port
MENU 5-5-1
0 9 0 5 0
This menu programs the 5 digit MyAlarm Port number.
Range must be programmed within 0 to 65535.
MENU 5-5-1 should be left at the factory default
settings unless you are advised otherwise by the
manufacturer.
1) Enter [5] + [5] + [1] + [OK]. Use the arrow keys to
select the IP port to program, then press the [OK]
key. The keypad will display the current MyAlarm
Port number.
Primary IP Port
09050
Press 0-9 OK to SAVE
2) Using the numeric keys, enter the IP address
required, then press [OK] to save and exit, or press
[MENU] to exit without saving.
Comms > MyAlarm >
MyAlarm Options
MENU 5-5-2
1 Disp Eth/WiFi Poll Fail N
2 Rpt Eth/WiFi Poll Fail N
3 Disp Cellular Poll Fail N
4 Rpt Cellular Poll Fail N
5 Disable Eth/WiFi MyAlar N
6 Reserved N
7 Reserved N
8 Static IP N
This location is a Bit option field.
Disp Eth/WiFi Poll Fail
This option allows the keypad to display a trouble
condition when the control panel fails to poll successfully
to the MyAlarm server for a period of 10 minutes via an
optional ethernet module or keypad with built-in Wi-Fi.
Rpt Eth/Wi-Fi Poll Fail
This option allows the control panel to report both poll
fail and poll fail restore events when the control panel
fails to poll successfully to the MyAlarm server via an
optional ethernet module or keypad with built-in Wi-Fi.
Displ Cellular Poll Fail
This option allows the keypad to display a trouble
condition when the control panel fails to poll successfully
to the MyAlarm server for a period of 20 minutes via an
optional GPRS module.
Rpt Cellular Poll Fail
This option allows the control panel to report both poll
fail and poll fail restore events when the control panel
fails to poll successfully to the MyAlarm server via an
optional GPRS module.
Disable Eth/WiFi MyAlarm
This option allows the installer to disable communication
between the control panel and the MyAlarm server via an
optional ethernet module or keypad with built-in Wi-Fi.
Static IP
This option allows the installer to fix both the MyAlarm
primary and secondary IP address in MENU 5-5-0.
To Next Page
