Bosch Solution 6000-IP Installation Guide

13-1
Bosch Security Systems 10/22 BLCC615I

SECTION 13
Specifications
Specifications
Electrical
Voltage Input
• 16 - 22 VAC
Current Requirement
• 22 VA min plug pack adapter or transformer
Panel Current Consumption
• 110 ma standby
Power Outputs
Continuous Power
• 1 Amp (Primary supply source only)
Secondary Source
• 5 Amp (Total with both primary and secondary source
combined)
Stand-By Battery
• 12 VDC, 7AH sealed rechargeable battery
Min Operating Voltage
• 10.2 VDC
LAN BUS
• Max total LAN length using multi strand security cable
= 300m.
• Max total LAN length using 2 pair twisted shielded data
cable (Belden 8723) = 1200m.
Temperature
0
o
to 55
o
C.
Relative Humidity
5 to 85% at 30
o
C non-condensing.
Enclosure Dimensions
MW720 - 385mm (W), 260mm (H), 90mm (D)
MW730 - 385mm (W), 520mm (H), 90mm (D)
PCB Dimensions
235mm (W), 40mm (H), 85mm (D)
Warranty
3 years from date of manufacture
Approvals
♦ EN 55022:2006
♦ EN50131-3:2009 (Grade 2 - Class II)
♦ AS/NZS CISPR 22:2006
♦ EN 60950-1:2001 Amdt 11:2004
♦ AS/NZS 60950.1:2003 Amdt 1:2006
♦ AS/ACIF S002:2005
♦ PTC200 May 2006
♦ ETSI TS 103 021-1, 2 & 3
Compatible Keypads
♦ CP155B - External Keypad with S/C Reader
♦ CP156B - Slim Style External Metal Keypad with S/C
Reader
♦ CP722B - Graphic Keypad Smart Card Reader (White)
♦ CP732B - Graphic Keypad Smart Card Reader (Black)
♦ PR113B - Internal Smart Card Reader (Black)
♦ PR114B - Internal Smart Card Reader (White)
♦ PR115B - External Smart Card Reader (Black)
♦ PR116B - External Smart Card Reader (White)
♦ CP741B - Graphic Keypad With Wi-Fi (White)
Expansion Devices
♦ CM195B - Multi RF Receiver Interface
♦ CM368B - IP Communications Module 4G GPRS Module
♦ CM430S - LAN to Ethernet Converter Module
♦ CM704B - 8/16 Zone Input Expander
♦ CM705B - Universal Expansion Module
♦ CM707B - 8/16 Piggy Back Zone Input Expander Module
♦ CM710B - 4-Way Relay Output Module
♦ CM720B - 1 Amp Power Supply Module
♦ CM723B - LAN 5 Amp P/S Module/Dual Battery Chargers
♦ CM724B - LAN 5 Amp P/S Module/Dual Battery Chargers
♦ CM746B - Plug On 4G GSM/GPRS Module
♦ CM751B - TCP/IP Interface Module
♦ CM760B - Real Time Clock Module
♦ CM797B - LAN Isolator Module
♦ CM796B - Wiegand to RS485 LAN Interface Module
♦ RF120 - Smart RF LAN Base Station Receiver 2-Way
♦ RF121 - Smart RF LAN Base Station Receiver With 4 Relay
Outputs 2-Way
♦ RF160 - Smart RF 2 Channel Wireless Output Module

Bosch Solution 6000-IP Specifications

General

Event Log	Yes
Areas	1
Partitions	1
Outputs	2
Communication	IP, GSM
Mobile App	Yes
Automation	Yes
System Type	Hybrid
Battery Backup	Yes
Keypads	Up to 8
