Solution 6000-IP
Installation Manual Input Programming
7-13
Bosch Security Systems 10/22 BLCC615I
Inputs > RF Zone > RF Zone Properties
Zone Options
MENU 3-3-3-3
1 Enable Rear Tamper N
2 Enable Case Tamper N
3 Reserved N
4 Reserved N
5 Reserved Y
6 Reserved N
7 Reserved N
8 Reserved N
This menu allows you to enable various zone options for
Digiflex RF Sensors.
1) Press [MENU] + [3] + [3] + [3] + [3]. The keypad will
display the current input options.
Enable Rear Tamper
Enable Case Tamper
Response Time 500msec
Press OK ON OFF MENU
2) Use the up and down arrow keys to highlight the
option then press the [ON] key to enable or the
[OFF] key to disable.
3) Repeat Step 2 until all options are programmed as
required, then press [OK] to save and exit or press
[MENU] to exit without saving.
Enable Rear Tamper
Setting this option will monitor the rear tamper of the
Digiflex RF Sensor.
Enable Case Tamper
Setting this option will monitor the case tamper of the
Digiflex RF Sensor.
GLOBAL INPUT OPTIONS
Inputs > Global Input Options >
EOL Value
MENU 3-4-0
(*** System Wide Parameter ***)
0 5
00 - No EOL 08 - 6k8 Ohm
01 - 1k0 Ohm 09 - 8k1 Ohm
02 - 1k5 Ohm 10 - 10k Ohm
03 - 2k2 Ohm 11 - 6K8 Alarm + 2k2 Tamp
04 - 2k7 Ohm 12 - 10k Alarm + 10k Tamp
05 - 3k3 Ohm 13 - 22k Ohm
06 - 4k7 Ohm 14 - 3k3 Alarm + 6k8 Tamp
07 - 5k6 Ohm 15 - Split EOL 3k3 //6k8
This menu programs the End Of Line resistor (EOL) value
that is global for all hard-wired zones including zones on
the Zone Expander Module. Only one EOL Value can be
programmed.
Setting the EOL Value to type 0 to 14 will configure the
control panel as 8 hardwired zones. Additional zones
via optional zone expander boards will start on zone 17.
Setting the EOL as type 15 will configure the control panel
as 16 hardware zones with zones 17 upwards via optional
zone expander boards.
1) Press [MENU] + [3] + [4] + [0]. The keypad will
display the current EOL value (Default = 5).
EOL Value
05 - 3k3 Ohm
Press 0-9 OK to SAVE
2) Use the up and down arrows to select the EOL
Value you want to use then press [OK] to save and
exit or press [MENU] to exit without saving.
Inputs > Global Input Options >
Keyswitch Options
MENU 3-4-1
(*** System Wide Parameter ***)
0 0
00 - Latching All On/Off 05 - Pulse All On/Off
01 - Latching All On 06 - Pulse All On
02 - Latch Part On/Off 07 - Pulse Part On/Off
03 - Latching Part On 08 - Pulse Part On
04 - Latching Off 09 - Pulse Part Off
This menu programs the properties for any zone in the
system programmed as a keyswitch zone. Only one
option can be selected for the entire system which means
that all keyswitches fitted will behave the same way.
The system can send Open and Close reports based on the
keyswitch operation with the zone number representing
the user number in the report.
