SYSTEM POWER OPTIONS
System > Power >
AC Options
MENU 7-3-0
1 Display AC Fail Y
2 Report AC Fail Y
3 Reserved Y
4 Random AC Report 2hr N
5 AC Fail After 1hr N
6 Reserved N
7 Reserved N
8 Reserved N
(*** System Wide Parameter ***)
This menu option allows you to configure the AC Mains
Power system options.
1) Press [MENU] + [7] + [3] + [0]. The keypad will
display the current AC Options.
Display AC Fail
Report AC Fail
Sync Clock To AC
Press OK ON OFF MENU
2) Use the up and down arrow keys to highlight the
option then press the [ON] key to enable or the
[OFF] key to disable.
3) Repeat Step 2 until all options are programmed as
required, then press [OK] to save and exit or press
[MENU] to exit without saving.
Display AC Fail
Setting this option will cause the panel to flash the
Mains Power icon as soon as the AC power supply has
failed. If the power remains missing continiously for 1
minute then a system trouble will be registered on the
keypad. When the AC power supply returns to normal the
Mains Power icon will remain on steady. If this option is
disabled then the system will not flash the Mains Power
icon and no system trouble will occur.
Report AC Fail
Setting this option will cause the panel to report an
AC Fail to the base station if the mains power has been
missing for a period of 1 minute. A restore report will be
sent once the mains power has been restored for one
minute.
Random AC Reporting 2hr
Setting this option allows the panel to randomly delay
(up to 2 hours) the AC Fail report. This option is used
to prevent multiple panels from reporting AC fail at the
same time.
AC Fail After 1 Hour
Setting this option will cause the panel to only send an
AC Fail report to the base station if the power has been
missing continuously for one hour. The Mains Power icon
will operate as normal.
System > Power >
Battery Options
MENU 7-3-1
1 Display Battery Fail Y
2 Report Battery Fail Y
3 Battery Test On Arming Y
4 OK To Arm Low Battery Y
5 Reserved N
6 Reserved N
7 Reserved N
8 Reserved N
(*** System Wide Parameter ***)
This menu option allows you to configure the standby
Battery system options. The system is constantly
monitoring the battery condition with a dynamic battery
test carried out every 4 hours.
1) Press [MENU] + [7] + [3] + [1]. The keypad will
display the current Battery Options.
Display Battery Fail
Report Battery Fail
Battery Test On Arming
Press OK ON OFF MENU
2) Use the up and down arrow keys to highlight the
option then press the [ON] key to enable or the
[OFF] key to disable.
3) Repeat Step 2 until all options are programmed as
required, then press [OK] to save and exit or press
[MENU] to exit without saving.
Display Battery Fail
Setting this option will cause the keypad to display
a Trouble condition when the panel detects that the
standby battery is disconnected or that its voltage is low.
The trouble condition will clear as soon as the panel has
measured the battery voltage is 12.5 volts or greater.
Report Battery Fail
Setting this option will cause the panel to send a Low
Battery report to the base station when it measures
the battery voltage has dropped below 11.5 volts. A
Low Battery Restore report will be sent when the panel
detects that the battery voltage is above 12.5 volts.
If the panel fails to detect the battery, or if it measures
the battery voltage below 10.2 volts, then a Battery Test
Failed report will be sent. A Battery Test restore will be
sent when the battery is re-connected or replaced.
