Solution 6000-IP
Installation Manual Output Programming
8-19
Bosch Security Systems 10/22 BLCC615I
So now you have an output that operates when the RF
Keyfob is used and another output when the iFob app
operates the DOOR shortcut. This requires 2 outputs both
connected to the garage door controller and increases the
number of physical outputs required to do the job. This
is further complicated when there are multiple doors and
gates all requiring the same functionality.
Now using Macros its easy to setup virtual outputs to do
these functions and then link the outputs together using
a Macro.
For this example we will use OP5 to connect to the garage
door controller and virtual outputs OP20 and OP21. A
virtual output is any output that is there from a software
point of view but there is no actual output card that is
taking care of the output.
OP5 Event Type=Macro 1
OP20 Event Type=Keyfob Function 2
OP21 Event Type=Door 1
Macro 1 Script=o20|o21
From the macro scrip you will see that output 20 or output
21 operating will cause the macro to become true so then
output 5 will operate.
Output Commands Macro Status Menu 4-0-6 you can see
the macro true false condition.
Outputs > Macros >
Name
MENU 4-8-0
M a c r o s 1 N a m e
This menu allows you to program the name for each macro.
A maximum of 8 different macros can be configured.
Macro names can be up to 20 characters long.
1) Press [MENU] + [4] + [8] + [0] and use the up and
down arrows to highlight the macro in the list then
press [OK]. Alternatively, you can enter the macro
number directly and press [OK].
2) Use the arrow and number keys to move and
change text. When the macro name is complete,
press [OK]. At any time you can press the [OFF] key
to clear the text from the current cursor position to
the end of the line.
Name MA1
Macro 1 Name
Press OK to SAVE
See Alpha Text Programming in Section 4 —
Programming Overview for further detail on entering
alpha text.
Outputs > Macros >
Macro Rule
MENU 4-8-1
This menu allows you to program the script for each macro.
A maximum of 8 different macros can be configured.
Macro scripts can be up to 20 characters long.
1) Press [MENU] + [4] + [8] + [1] and use the up and
down arrows to highlight the macro in the list then
press [OK]. Alternatively, you can enter the macro
number directly and press [OK].
2) Use the arrow and number keys to move and
change text. When the macro script is complete,
press [OK]. At any time you can press the [OFF] key
to clear the text from the current cursor position to
the end of the line.
Macro Rule MA1
Press OK to SAVE
For information on both macros script and operator
characters, refer to both "Table 22: Macros Script
Characters" on page 8-17 and "Table 23: Macros
Operator Characters" on page 8-17.
See Alpha Text Programming in Section 4 —
Programming Overview for further detail on entering
alpha text.
