M710 User Manual 20
Setup
Loading Supplies
Loading Bulk Labels
1. Remove the M710 label core and
the label feed ramp from the box.
2. On the bulk label supply box, push
in tab A, then pull the perforated flap
down and tear off.
3. Attach the label feed ramp to the
bottom of the perforation, with the
ramp arms on the outside of the box.
4. Attach the ramp hooks to the outside
of the bulk label feed path on the
printer.
5. Open the printer and insert the label core making sure the smart cell on the label roll aligns
with the reader in the label well.
