M710 User Manual 50
Editing Labels on the Printer
Graphics
4. Select the desired symbol.
5. Press or ENTER.
The symbol displays with the same font size that is currently in use.
To remove a symbol from the label:
1. Position the cursor to the right of the symbol.
2. Press .
Graphics
Graphics are symbols, logos, or other artwork supplied from an outside source, such as a computer.
These graphics must be bitmap files (*.bmp) and can only be black and white. The printer will
automatically resize the graphic, but it is important to keep the graphic size approximate to the printed
output (about 2-inch x 2-inch). The imported graphic file size cannot exceed 40KB.
Import Graphics
Graphics are added to the printer through the Import function. This function displays in the File menu if
a USB drive is attached.
To import graphics to the printer:
1. Download a graphic from the computer to a USB drive.
2. Plug the USB drive containing the graphic into the printer.
3. Press FN + FILE.
4. Tap Import.
5. Select Graphics, then choose the graphic and press .
Graphic files (.bmp) are stored on the printer in a specific folder used by the Graphics function. This
folder is unavailable to the user and therefore, when importing a graphic, the destination screen does
not display. Unlike symbols, imported graphics are not categorized. However, the most recently used
graphic displays first in the window.
For a more comprehensive discussion of importing files, refer to “Using Files from a USB Drive” on
page 83.
Add a Graphic
To add a personal graphic to your label:
1. Position the cursor at the point where you want the graphic to display.
2. Press FN and GRAPHICS to view the graphics saved to the printer.
