M710 User Manual 26
General Operation
Using the Touchscreen
7. Battery charge remaining. The gauge turns red when only 10% of the battery charge
remains.
8. Bluetooth indicator.
•
No icon:
Bluetooth is not turned on. See
“Bluetooth” on page 13
.
•
Grey icon:
No one is using the Bluetooth connection.
•
Blue icon:
At least one person is using the Bluetooth connection.
9. Wi-Fi indicator
Indicates that Wi-Fi is connected.
Indicates that Wi-Fi is on, but disconnected.
No icon indicates that Wi-Fi is off.
10. Character Attributes. If bold, italic, or underline are set, a symbol here indicates which are
set. Blank means no character attributes are set. B means bold, I means italic, and U
means
underline. These can be combined if multiple attributes are set. The slanted, underlined B in
the image above indicates that all three attributes are applied.
11. Function. The letters FN here indicate that the FN key has been pressed. This is used in
combination with keys that have orange text on them. Pressing FN and then another key
performs the function written in orange.
12. Caps lock. This symbol is visible when the caps lock is on.
13. Ribbon remaining. The gauge turns red when only 10% of the ribbon remains.
14. Label supply remaining. The gauge turns red when only 10% of the label supply remains.
15. Rotation. Degrees that the label is rotated. See “Rotation” on page 46.
16. Font size. The letter "A" indicates that it is set to Auto. See “Font Size” on page 40.
