Brother MFC-L2700D Service Manual

3-65
Confidential
(4) Slide the CIS carriage slowly to the location shown in the figure below.
(5) Open the first side CIS unit at 90 degrees to the CIS carriage, and slide it in the direction
of the arrow to remove it by releasing the two bosses. Disconnect the first side CIS flat
cable from the first side CIS unit.
Fig. 3-60
Assembling Note:
• Acquire the white level data, and set the CIS scanning area.
(Refer to “Acquire white level data and set CIS scan area (function code: 55)” in
Chapter 5.)
First side CIS unit
CIS carriage
First side CIS flat cable
First side CIS unit
Boss
Boss
CIS carriage

Brother MFC-L2700D Specifications

General

Print Technology	Laser
Print Resolution	Up to 2400 x 600 dpi
Duplex Printing	Yes
Paper Input Capacity	250 sheets
Monthly Duty Cycle	Up to 10, 000 pages
Functions	Print, Copy, Scan, Fax
ADF Capacity	35 sheets
Memory	32 MB
Fax Speed	33.6 Kbps
Print Speed	Up to 27 ppm
Connectivity	USB 2.0
Scanner Type	Flatbed
Copy Speed	Up to 27 cpm
Scan Resolution	Up to 600 x 2400 dpi
Display	2-line LCD
