Brother MFC-L2700D Service Manual

2-54
Confidential
 Error code BB00
A white level not within the standard was scanned when function code 55 was executed.
 Error code BC00
When scanning the fax, white or black correction data for the second side CIS was not within
the correct range. (Second time)
 Error code BD00
A black level not within the standard was scanned when function code 55 was executed.
Scanner Error
-
Step Cause Remedy
1
Dirt on the second side
document hold
Clean the second side document hold.
2
Dirt on the white tape Clean the white tape.
3
First side CIS unit failure Replace the first side CIS unit.
4
Second side CIS unit failure Replace the second side CIS unit.
5
Second side document hold
failure
Replace the ADF unit.
6
White tape failure Replace the document scanner unit.
7
Main PCB failure Replace the main PCB ASSY.
-
Step Cause Remedy
1
Incorrect correction data for
second side CIS unit
Execute "Set CIS scan area (function code:
55)".
2
Second side CIS unit failure Replace the second side CIS unit.
3
Main PCB failure Replace the main PCB ASSY.
Scanner Error
-
Step Cause Remedy
1
Dirt on the second side
document hold
Clean the second side document hold.
2
Dirt on the white tape Clean the white tape.
3
First side CIS unit failure Replace the first side CIS unit.
4
Second side CIS unit failure Replace the second side CIS unit.
5
Second side document hold
failure
Replace the ADF unit.
6
White tape failure Replace the document scanner unit.
7
Main PCB failure Replace the main PCB ASSY.

Brother MFC-L2700D Specifications

General

Print Technology	Laser
Print Resolution	Up to 2400 x 600 dpi
Duplex Printing	Yes
Paper Input Capacity	250 sheets
Monthly Duty Cycle	Up to 10, 000 pages
Functions	Print, Copy, Scan, Fax
ADF Capacity	35 sheets
Memory	32 MB
Fax Speed	33.6 Kbps
Print Speed	Up to 27 ppm
Connectivity	USB 2.0
Scanner Type	Flatbed
Copy Speed	Up to 27 cpm
Scan Resolution	Up to 600 x 2400 dpi
Display	2-line LCD
