5.4 Image Extension QUANTAX EDS
57
5.4
Image Extension
This section describes the automatic capturing of multiple microscope images using sample stage
movement. The images are put together into a mosaic image instantly.
Step
Example/hints
1
Select a workspace (
Objects, Line
scan,
Mapping, or Imaging).
These workspaces allow capturing an EM
.
2
Set image resolution and dwell time.
Refer to section 5.3.
3
Click
to adjust image contrast
and brightness.
Use histogram settings and oscilloscope
overlay tools if needed
.
4
Click
on the button to
open the Capture parameters menu.
5
Set Image number or Automatic
numbering.
6
Select Activate in the Image extension
submenu.
7
Set Width and Height.
E.g., 2 x 3 means that 2 images in x direction
and 3 images in y
direction will be captured.
Th
e current stage position is in the center of
the mosaic image.
8
the extended image.
9
Use the image chart icon to
a) Save image
b) Add image to project
Alternatively, click with the right mouse
button into the image or drag and drop
it to
Project
or Report. If an analysis of this area
is required, follow the corresponding guide
(section 5.14, 5.15 or 5.17).
c) Add image to report.
