Bruker QUANTAX EDS User Manual

5.3 Image Capture QUANTAX EDS
55
5.3
Image Capture
This section describes how to capture electron microscope images with the ESPRIT software.
Step
Example/hints
1
Select a workspace (Objects, Line scan,
Mapping, or Imaging).
These workspaces allow capturing an EM
.
2
Use the
icon in the bottom left
corner of the
Scan configurator to open
the SCAN CONFIGURATION dialog.
3
Set image resolution (pixel).
Th
e parameters in steps 3, 4, and 5 affect
the
total
Image capture time.
4
Set dwell time [µs].
5
Set line average.
6
Click
and set image contrast
and brightness
on the microscope.
Use histogram settings and oscilloscope
overlay tools if needed
.
7
C
lick on the button to
s
et capture parameters and Image
number
or Automatic numbering.
The image will have the name set in the
Sample
configurator. Choose Single to
acquire one image
frame, Continuous to
update image frames or
Sliding average to
average a number of frames.
8
an image.
9
Image legend parameters can be edited
using the icon.
The image name can also be changed here
after capture
.
10
Toggle between two image channels if
available
.
Note that the image channel names can be
changed
in the System workspace under
Microscope to e.g. SE, BSE, HAADF… (see
section 4.7.6).
11
Use the image chart icon to
a) Save image
b) Add image to project
Alternatively, click with the right mouse
button into the image or drag and drop it to
Project
or Report. To perform image
processing, refer to section 5.6.
c) Add image to report.
