Rear Mounted Pinsetter Controllers
CONNECTOR LED
FUSE
(5x20mm)
DESCRIPTION
Even (Right) Lane
J1 D1 (Green)
F1 - F3
208/230V - (3A,250V Slow)
380/400V - (2A,250V Slow)
3-Phase Power Out - Pinsetter Motor
J4
D2 (Green)
F4
(2A,250V Slow)
Power Out - A/C Pinlight
J5
F5
(2A,250V Slow)
J9 D9 (Green)
F14
(1A,250V Slow)
Power Out - D/C Pinlight (White)
J11 D7 (Green)
F15
(1A,250V Slow)
Power Out - D/C Pinlight (Blacklight)
Odd (Left) Lane
J3 D5 (Red)
F11 - F13
208/230V - (3A,250V Slow)
380/400V - (2A,250V Slow)
3 Phase Power Out - Pinsetter Motor
J6
D4 (Red)
F9
(2A,250V Slow)
Power Out - A/C Pinlight
J7
F10
(2A,250V Slow)
J10 D11 (Red)
F16
(1A,250V Slow)
Power Out - D/C Pinlight (White)
J12 D13 (Red)
F17
(1A,250V Slow)
Power Out - D/C Pinlight (Blacklight)
Common
J2 D3 (Green)
F6 - F8
208/230V - (3A,250V Slow)
380/400V - (2A,250V Slow)
3-Phase Power - Ball Accelerator
J8 N/A N/A 3-Phase Power In
J13 N/A N/A Input - Motor / Pinlight Control
N/A D14 (Green) N/A DC Power LED
Figure3-17.HighVoltagePCB-Connector,LED,andFuseChartForREARMountedControllers
