323011 - D45/ip interFace
Prepare for the configuration lines
The D45/IP interface has options for downloading the configuration: online download, serial port download, and USB
download.
On completing the above configuration, press
to save the configuration for future view or maintenance.
Press
used for the download configuration.
Serial port
Connection for USB configuration download.
Connection for serial port configuration download
Connect the computer USB port
Connect the computer serial port or USB transfer to the serial port line
Connect the Ethernet port
Connection for Ethernet configuration download
USBLAN Serial Port
LAN
POWER SUPPLY 323010
323011
System accessories functions overview
