ITEM TORQUE NOTES
Crank pin nut 150-185 ft-lbs 203-251 Nm LOCTITE 620 RETAINING COMPOUND, page 3-59
Crankcase 1/4 in. screws 70-110
in-lbs
7.9-12.4 Nm page 3-63
Crankcase 5/16 in. screws 15-18 ft-lbs 20-24 Nm page 3-63
Crankcase cover screws 80-110
in-lbs
9.0-12.4 Nm special pattern to tighten, page 3-46
Cylinder head screws See note special pattern to tighten, page 3-20
Cylinder studs 10 ft-lbs 13.6 Nm install shoulder end down, page 3-63
Front isolator to
cylinder head bolt
73-78 ft-lbs
98.9-105.7
Nm
LOCTITE THREADLOCKER 262 (red), page 3-19
Front sprocket nut 150-165 ft-lbs 203-224 Nm LOCTITE THREADLOCKER 262 (red), page 3-63
Isolator bolt, front 100-110 ft-lbs
135.6-149.1
Nm
page 3-10
Isolator bolts, side 100-110 ft-lbs
135.6-149.1
Nm
LOCTITE THREADLOCKER 262 (red), page 3-10
Oil filter adapter 8-12 ft-lbs 11-16 Nm LOCTITE THREADLOCKER 242 (blue), page 3-37
Oil pressure signal light switch 5-7 ft-lbs 7-9 Nm page 3-37
Oil pressure switch wire nut 4-10
in-lbs
0.4-1.1 Nm page 3-37
Oil pump cover screws
125-150
in-lbs
14.1-16.9 Nm page 3-36
Oil pump mounting screws
125-150
in-lbs
14.1-16.9 Nm page 3-36
Pinion shaft nut 35-45 ft-lbs 47-61 Nm LOCTITE THREAD-LOCKER 262 (red), page 3-46
Rocker box bolts 10-13 ft-lbs 13.6-18 Nm page 3-21
Rocker box cover screws 10-13 ft-lbs 13.6-18 Nm page 3-21
Rocker box screws 90-120
in-lbs
10.2-13.6 Nm page 3-21
Rocker box to head bolts 15-18 ft-lbs 20-24 Nm 2 sizes, page 3-21
Swingarm mount
block bolts, lower
68-75 ft-lbs
92.2-101.7
Nm
page 3-10
Swingarm mount
block bolts, upper
41-45 ft-lbs 55.6-61.0 Nm page 3-10
Tappet plate screw 80-110
in-lbs
9.0-12.4 Nm page 3-20, page 3-39
Tappet retainer screw 11-15 ft-lbs 20-24 Nm page 3-20, page 3-39
Tie bar bolts 30-33 ft-lbs 40.7-44.7 Nm front tie bar uses LOCITITE PST SEALANT, page 3-10
