7-32
BATTERY
GENERAL
1
WARNING
Batteries contain sulfuric acid which can cause severe
burns. Avoid contact with skin, eyes or clothing.
Batteries produce explosive hydrogen gas at all
times, especially when being charged. Keep ciga-
rettes, open flame and sparks away from the battery
at all times. Ventilate area when charging battery.
Always protect hands and protect eyes with shield or
goggles when working near a battery or acid. KEEP
BATTERIES AND ACID OUT OF THE REACH OF CHIL-
DREN!
See Figure 7-31. The battery is below the seat in the center of
the vehicle.
The battery can be removed from the left side of
the motorcycle without removing the tail section or fuel tank.
NOTE
The battery requires no additional fluid at any time. See BAT-
TERY in Section 1 for removal/installation and charging pro-
cedures.
Figure 7-31. Battery
b0228x7x
1
1. Positive cable
2. Bolt
3. Negative cable
4. Battery strap
5. Locknut
6. Bottom pad
7. Battery
8. Rear pad
3
4
2
5
6
7
8
