7-38
TURN SIGNAL FLASHER
REMOVAL
NOTE
The turn signal flasher is not repairable. Replace the unit if it
fails.
1. Remove seat and tail section. See TAIL SECTION,
REMOVAL in Section 2.
2. See Figure 7-39. Remove screw from clamp.
3. Remove turn signal flasher and detach both wires.
INSTALLATION
1. See Figure 7-39. Connect both wires to flasher.
2. Place flasher inside clamp so prongs on flasher face
inside and down.
3. Install on flasher and clamp on frame with screw.
1WARNING
Check for proper turn signal operation before riding
motorcycle. Visibility is a major concern for motorcy-
clists. Failure to have proper turn signal operation could
lead to personal injury.
4. Check turn signals for proper operation.
Figure 7-39. Turn Signal Flasher
5682
Flasher

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Buell S1 Lightning and is the answer not in the manual?

Buell S1 Lightning Specifications

General IconGeneral
Transmission5-speed
Rear BrakesSingle 230mm disc, single-piston caliper
Compression Ratio10.0:1
IgnitionElectronic
Engine TypeAir-cooled, four-stroke, 45° V-twin
Rear SuspensionShowa monoshock, adjustable preload, compression and rebound damping
Front BrakesSingle 340mm disc, 6-piston caliper
Seat Height775 mm
Bore x Stroke88.8 mm x 96.8 mm
Fuel SystemCarburetor
FrameTubular steel
TiresFront: 120/70 ZR17, Rear: 170/60 ZR17
