ELECTRICAL CONNECTORS
GENERAL
The following table provides a brief description of the connec-
tors found on the S1 Lightning. Approximate locations of each
connector are shown in Figure 7-46.
Connector numbers are listed in [brackets] in this manual.
Table 7-5. Electrical Connectors
CONNECTOR
NUMBER
DESCRIPTION COMPONENT(S) ALSO SEE
[P1] 4-place Amp Multilock
right handlebar switch housing-
ignition power, module and starter
page 7-39
[P2] 2-place Amp Multilock front brake switch page 7-51
[P3] 12-place Amp Multilock instruments and indicator lamps page 7-51
[P4] 4-place Amp Multilock headlamp page 7-34
[P5] 2-place Amp Multilock clutch switch page 7-21
[P6] 8-place Amp Multilock
left handlebar switch housing-
horn, turn signals, lights
page 7-40
[P7] 2-place Deutsch vacuum-operated electric switch page 7-10
[P8] 4-place PED ignition/headlamp switch page 7-12
[P9] 4-slot fuse block
four 15 amp fuses for ignition,
instruments, lights and accessories
page 7-43
[P10] 8-place Deutsch ignition module page 7-13
[P11] 8-place Amp Multilock tail lamp and rear turn signals page 7-36
[P12] 4-place relay ignition relay page 7-22
[P13] 4-place relay starter relay page 7-22
[P14] 2-place Amp Multilock side stand switch page 7-21
[P15] 2-place Amp Multilock license plate light page 7-36
[P16] 3-place Deutsch timer and pickup page 7-13
[P17] 2-place plug voltage regulator page 7-31
