Buell S1 Lightning User Manual

7
CLUTCH
MODEL YEAR CHANGE
See Figure 5. All 1997 model year motorcycles use the new
style clutch release ramp introduced on late 1996 vehicles.
The clutch adjustment and lever freeplay procedures remain
the same. The change was made to provide additional clear-
ance between the coupler and the primary cover.
Figure 5. Ramp Change
New style Old style
5671

Buell S1 Lightning Specifications

General

Transmission	5-speed
Rear Brakes	Single 230mm disc, single-piston caliper
Compression Ratio	10.0:1
Ignition	Electronic
Engine Type	Air-cooled, four-stroke, 45° V-twin
Rear Suspension	Showa monoshock, adjustable preload, compression and rebound damping
Front Brakes	Single 340mm disc, 6-piston caliper
Seat Height	775 mm
Bore x Stroke	88.8 mm x 96.8 mm
Fuel System	Carburetor
Frame	Tubular steel
Tires	Front: 120/70 ZR17, Rear: 170/60 ZR17
