5-1
SPECIFICATIONS
STARTER
Free speed 3000 RPM (min.) @ 11.5 V
Free current 90 amp (max.) @ 11.5 V
Stall current 400 amp (max.) @ 2.4 V
Stall torque 8.1 ft-lbs (11.0 Nm) (min.) @ 2.4 V
SERVICE WEAR LIMITS IN. MM
Brush length minimum 0.433 11.0
Commutator diameter
minimum
1.141 28.98
5
ITEM TORQUE NOTES
Battery terminal hardware 30-40
in-lbs
3.4-4.5 Nm hold cable when loosening/tightening, page 5-17
Starter mounting bolts 13-20 ft-lbs 17.6-27.1 Nm page 5-17
