SPECIFICATIONS
BATTERY
Size 12 VDC
Type Sealed
SPARK PLUGS
Size 12 mm
Style 6R12
Gap 0.038-0.045 in. 0.96-1.14 mm
Torque value 11-18 ft-lbs 14.9-24.4 Nm
ALTERNATOR
AC voltage output 19-26 VAC per 1000 engine RPM
Stator coil resistance 0.2-0.4 Ohms
REGULATOR
Voltage output @ 75
°
F 13.8-15 VDC
Amperes @ 3600 RPM 22 Amps
IGNITION TIMING SPARK OCCURRENCE
Idle
V.O.E.S.
Connected Disconnected
World models
950-1050 RPM
20˚ BTDC
Approximately
7.5˚ BTDC
California models
1150-1250 RPM
20˚ BTDC
Approximately
7.5˚ BTDC
IGNITION COIL RESISTANCE
Primary winding 2.5-3.1 Ohms
Secondary winding 10,000-12,500 Ohms
ELECTRICAL SYSTEM AMPERES
Main circuit breaker 30
Ignition fuse 15
Light fuse 15
Accessory fuse 15
Instrument fuse 15
BULB CHART
Lamp Description (All Lamps 12 V)
Number Of
Bulbs Required
Specifications
Headlamp High/low replaceable bulb 1 60 W/55 W
Position lamp 1 14 W
Marker lamps Tail/stop lamp 1 5 W/21 W
Turn signal lamp-front and rear, 1 bulb per lamp 4 10 W
License plate lamp 1 5 W
Indicator lamps on
instrument support
High beam indicator 1 0.07 Amps/2 C.P.
Turn signal indicator 2 0.07 Amps/2 C.P.
Oil pressure indicator 1 0.07 Amps/4 C.P.
Neutral indicator 1 0.07 Amps/4 C.P.
Instruments Speedometer 2 0.22 Amps/2 C.P.
Tachometer 1 0.22 Amps/2 C.P.
