Buell S1 Lightning User Manual

7-25
Figure 7-19. Charging System Circuit
1
2
30A
MASTER
CIRCUIT
BREAKER
P17
BK
BK
BK
VOLTAGE REGULATOR
BK
BK
BK
BK
STATOR
BATTERY



LT.BE LIGHT BLUE
CABLE COLOR
BE
COLOR CODE:
BK
BN
GN
GY
O
BLUE
BLACK
BROWN
GREEN
GRAY
ORANGE
PINK
RED
TAN
VIOLET
WHITE
YELLOW
PK
R
TN
V
W
Y
STRIPE COLOR
XX XX
PIN CONNECTOR
SOCKET CONNECTOR
NO CONNECTION
CONNECTION
DIODE
b0240x7x

Buell S1 Lightning Specifications

General

Transmission	5-speed
Rear Brakes	Single 230mm disc, single-piston caliper
Compression Ratio	10.0:1
Ignition	Electronic
Engine Type	Air-cooled, four-stroke, 45° V-twin
Rear Suspension	Showa monoshock, adjustable preload, compression and rebound damping
Front Brakes	Single 340mm disc, 6-piston caliper
Seat Height	775 mm
Bore x Stroke	88.8 mm x 96.8 mm
Fuel System	Carburetor
Frame	Tubular steel
Tires	Front: 120/70 ZR17, Rear: 170/60 ZR17
