Ignition Circuit
Remove W/BK wire from ignition coil.
Connect a test light or voltmeter to the vehicle.
a. Attach one end to W/BK wire terminal.
b. Attach the other end to vehicle ground.
Turn ignition switch to IGN.
Set engine stop switch to RUN.
Place motorcycle in neutral. Is current present?
NO
YES
Place motorcycle in first gear.
Is current present?
Check neutral switch and circuit. See NEUTRAL INDI-
CATOR SWITCH in Section 7 of the 1996 manual.
Repeat entire ignition portion of interlock circuit test
when finished.
NO
Retract side stand.
Is current present?
YES
Check neutral switch. See NEUTRAL INDICATOR
SWITCH in Section 7 of the 1996 manual. Repeat
entire ignition portion of interlock circuit test when fin-
ished.
NO
Check side stand switch. See STARTER INTERLOCK
in Section 7 of the 1996 manual. Repeat entire ignition
portion of interlock circuit test when finished.
YES
Extend side stand.
Pull-in clutch lever. Is current present?
NO
Check clutch switch. See STARTER INTERLOCK in
Section 7 of the 1996 manual. Repeat entire ignition
portion of interlock circuit test when finished.
YES
Ignition circuit operating properly.
a. Turn ignition switch to LOCK.
a. Set engine stop switch to OFF.
b. Remove test light or voltmeter.
c. Reconnect W/BK wire to ignition coil.
d. Remove REAR WHEEL SUPPORT STAND.
