Chapter 2 BK730-2 Base Page 2-13
made “on the fly”. This type of control enables end users to modify the system’s speed
without having to worry about incorrectly setting the speed of upstream or downstream
equipment due to the intelligence built into the solution.
Historically, operators were required to adjust the speeds of each individual unit in the
production line separately to achieve a desired throughput. Depending on the complexity
of the system, this can be a challenge due to material handling and material transport
requirements.
Since this is an option, every Buskro Tabber base will come pre-wired from the factory for
use with a Speed Control Board by using a pass-thru Dummy Speed Control Board (p/n
9103875). This “dummy” board allows for all of the required electrical connections to be
installed without affecting system operation.
Such a design methodology is consistent with Buskro’s vision for versatility as customer
requirements change and grow. At any point, a Speed Control Board can be purchased
from Buskro Ltd. and installed to replace the Dummy Speed Control board to enable the
features. The dummy board is illustrated in Figure 2-6 as a reference.
Dummy Speed Control Board
(p/n 9103875 )
Figure 2-6: Dummy Speed Control Board
Buskro Ltd. BK730-2 Tabber
