Curves Dialog Box
Curves Dialog Box
This dialog box appears when you click the Curves button on the Color Settings Sheet. You can set Channel and
other settings.
•
Channel
Select from among RGB, Red, Green, or Blue.
Note
• Gray is displayed for monochrome printing and this selection cannot be changed.
• Input
Enter an input value.
Note
• The allowed entry range is 0 to 255.
• You can change the numbers by clicking either ▲ button or ▼ button.
•
Output
Enter an output value.
Note
• The allowed entry range is 0 to 255.
• You can change the numbers by clicking either ▲ button or ▼ button.
•
Load Curves button
Click the button to load stored data for a tone curve.
•
Save Curves
button
Click the button to stores the current tone curve settings.
