Canon imagePROGRAF iPF8400S - Removing the Roll Holder from Rolls

8
Lower the Ejection Guide and close the Top Cover.
Note
• To load new paper in the printer at this point, see "Loading Rolls in the Printer." ➔ P.510
• Clean inside the top cover before loading paper.
(See "Cleaning Inside the Top Cover.") ➔ P.907
Removing the Roll Holder from Rolls
Removing the Roll Holder from Rolls
1
Lift the Holder Stopper lever (a) from the shaft side to un-
lock it. Holding the Holder Stopper at the position indica-
ted (b), remove it from the Roll Holder.
2
Remove the Roll Holder from the roll.
iPF8400S Removing the Roll Holder from Rolls
User's Guide
Handling and Use of Paper Handling rolls
519
