e
Roll Holder
Load the roll on this holder.
f
Ejection Support
Prevents printed documents from winding around the Roll Holder or being drawn into the Paper Feed Slot.
g
Output Stacker
A cloth tray that catches ejected documents. (See "Parts of the Output Stacker.")
➔P.541
h
Paper Feed Slot
When loading a roll, insert the edge of the roll paper here.
i
Holder Stopper
Secure rolls on the Roll Holder with this part.
j
Ink Tank Cover
Open this cover to replace an Ink Tank. (See "Ink Tank Cover (Inside).") ➔ P.663
k
Control Panel
Use this panel to operate the printer and check the printer status. (See "Control Panel.") ➔ P.622
l
Release Lever
Releases the Paper Retainer. Lift this lever toward the front of the printer when loading paper.
m
Maintenance Cartridge
Absorbs ink used for maintenance purposes such as head cleaning. (Replace the cartridge when it is full.)
n
Carrying Handles
When carrying the printer, have six people hold it by these handles under both sides.
o
Maintenance Cartridge Cover
Open this cover to replace the Maintenance Cartridge.
p
Stand
A stand that holds the printer. Equipped with casters to facilitate moving it. (See "Stand.") ➔ P.664
