Step Action Illustration
4 [Remove the 2 plugs from the heat ex-
changer.]
5 [Use the socket wrench to loosen the 2
fixation pens.]
4
Replace the Heat Exchanger Foils
386
Chapter 18 - Printer Operation Care (POC)
Canon varioPRINT 135 Series
