CDE360 Vector Control AC Drive Introduction
3.4) Set the running frequency of the AC drive (salve address is 1) to 25 Hz by writing the data to
the register 0x6400 with the communication function code 0x06.
Remarks: 0x1388 corresponds to 5000 in decimal, which means 50 percents as communication setting value.
When the communication setting value is used for reference frequency, the base value is b0.00(Max
frequency,default 50Hz).
3.5) Run the AC drive (slave address is 1) forward by writing the data to the register 0x6401 with the
communication function code 0x06.
3.6) Stop the AC drive (slave address is 1) by writing the data to the register 0x6401 with the
communication function code 0x06.
Remarks: 0x6401 command function
