Cardinal 201 User Manual

Model 201 Installation & Technical
8400-M117-O1 Rev D
Page 82
out 2= (Digital Output 2)
Press the F3/  key to show the current setting. If the setting
displayed is acceptable, press the F3/  key again to save it.
Otherwise, use the F2/ key to toggle to a new setting and then
press the F3/  key to save it. Allowable settings are:
Selection
Function
off
Off (Digital Output 2 is disabled)
Under
Check weigh Under
ACCEPT
Check weigh Accept
oEr
Check weigh Over
out 3= (Digital Output 3)
Press the F3/  key to show the current setting. If the setting
displayed is acceptable, press the F3/  key again to save it.
Otherwise, use the F2/ key to toggle to a new setting and then
press the F3/  key to save it. Allowable settings are:
Selection
Function
off
Off (Digital Output 3 is disabled)
Under
Check weigh Under
ACCEPT
Check weigh Accept
oEr
Check weigh Over
out 4= (Digital Output 4)
Press the F3/  key to show the current setting. If the setting
displayed is acceptable, press the F3/  key again to save it.
Otherwise, use the F2/ key to toggle to a new setting and then
press the F3/  key to save it. Allowable settings are:
Selection
Function
off
Off (Digital Output 4 is disabled)
Under
Check weigh Under
ACCEPT
Check weigh Accept
oEr
Check weigh Over
