3-CONTROLSANDINSTRUMENTS
(15)FUELGAUGE:
Thefuelgaugeconsistsofaseriesofbars
thatindicatetheleveloffuelinthefuel
tank.Whenall8barsarevisiblethefuel
tankisfull.Bottombarashingindicates
approximately3.8L(1.0USgal)offuel
remaining.
(16)ENGINECOOLANTTEMPERATUREBAR
GRAPH:
Thisbargraphindicatestherelative
temperatureoftheenginecoolantfrom
0–110°C(32–230°F).Ifthecoolant
temperaturerisesabove110°C(230°F),all
8barswilldisplay,thebacklightingwillash,
andtheaudiblealarmwillsound.
(17)HYDRAULICFLUIDTEMPERATUREBAR
GRAPH:
Thishydraulicoiltemperaturebargraph
indicatestherelativetemperatureofthe
hydraulicoilfrom0–110°C(32–230°F).If
thetemperatureexceeds110°C(230°F),all
8graphsegmentswilldisplay,backlighting
willash,andtheaudiblealarmwillsound.
93109329A6
3-40
