CustomEHsettings
RAIL13SSL0756GA5
MenustructureforElectro-Hydraulic(EH)controls
MenustructureforElectroHydraulic(EH)controls
Setup
Displaysetupmenu.Tilt
Attachmenttiltfunction.
ExitExitthesetupmenu.L-ARMLoaderarm.
EH
Customizethespeedofthemachine’sEH
controls.
High
Quickresponsetocontrollevermovement.
DSPLY
Alternatemethodtoselectbetweenthe
selecteddisplayparameters.
Med-2
Medium/quickresponsetocontrollever
movement.
UNITS
Allowstheoperatortoselectbetween
Fahrenheit/ImperialunitsandCelsius/SI
units.
Med-1
Medium/slowresponsetocontrollever
movement.
JTIMEJobTimer.Displaysengineoperatinghours
sincelastreset.
Low
Slowresponsetocontrollevermovement.
Lock
Usedtocreate/changeowneranduser
codes.
DRV1Aggressiveresponsetocontrollever
movement.
SpeedSpeedofthedrive,lift,andtiltfunctions.
DRV2Mediumresponsetocontrollever
movement.
CTRLControlsfordriveandloaderarm.
DRV3
Smoothresponsetocontrollever
movement.
DFLT
Factorydefaultsettings.
LDR1Aggressiveresponsetocontrollever
movement.
Drive
Travelforwardandreversefunction.
LDR2Mediumresponsetocontrollever
movement.
LiftLoaderarmupanddownfunction.
LDR3
Smoothresponsetocontrollever
movement.
DefaultsettingsformodelsSR130andSR150
SPEED
TiltLowMed-1Med-2High
Lift
LowMed-1Med-2High
DriveLowMed-1Med-2High
CTRL
DriveDRV3DRV2DRV1
