5-TRANSPORTOPERATIONS

SV185only

Frontslingrequirements:

•

Twosyntheticslings3.7m(12.0ft)inlength.

•

Eachslingmusthavearatedliftingcapacityofequalto

orgreaterthan0.552xGrossVehicleWeight(GVW).

Rearslingrequirements:

•

Twochainsapproximately2.2m(7.1ft)inlength.

Someadjustmentmayberequiredforalevellift.

•

Eachchainmusthavearatedliftingcapacityofequalto

orgreaterthan0.676xGrossVehicleWeight(GVW).

RAIL14SSL0398BA16

NOTE:Foraclearviewofthemachine’sliftingpointsand

theslingroutingtheloaderarmisnotshown.Donot

removetheloaderarms.

Ateachofthemachine’sliftingpointswillbealiftingpoint

decal.

RAIL14SSL0399BA17

5-8
