5-TRANSPORTOPERATIONS

SV250,SV300,andTV380

Frontslingrequirements:

•

Twosyntheticslings3.7m(12.0ft)inlength.

•

Eachslingmusthavearatedliftingcapacityofequalto

orgreaterthan0.368xGrossVehicleWeight(GVW).

Rearslingrequirements:

•

Twochainsapproximately2.0m(6.5ft)inlength.

Someadjustmentmayberequiredforalevellift.

•

Eachchainmusthavearatedliftingcapacityofequalto

orgreaterthan0.851xGrossVehicleWeight(GVW).

RAIL14SSL0478BA21

NOTE:Foraclearviewofthemachine’sliftingpointsand

theslingroutingtheloaderarmisnotshown.Donot

removetheloaderarms.

Ateachofthemachine’sliftingpointswillbealiftingpoint

decal.

RAIL14SSL0479BA22

5-10
