6-WORKINGOPERATIONS

Installingtheattachment

NOTICE:Readthemanufacturer’sinstructionmanualforattachmentsnotincludedinthismanual.

Apivotingcoupler(1)issuppliedwiththeskidsteeras

standardequipmentandremainsattachedtotheloader

liftarm.

931007516A1

1.Rotatethelatchhandles(2)uptotheunlatchedposi-

tion.Besurethelatchhandlesareallthewayupso

thelockpinsarefullyretracted.

9310075162

2.Hydraulicallytiltthecouplers(3)forwardwhileguiding

thecrestofthecouplerundertheattachmentsaddle.

9310075173

6-2
