6-WORKINGOPERATIONS
3.Raiseandcurlthecoupleruntilthebacksurfaceofthe
attachmentcomestorestatagainstthefrontsurface
ofthecoupler.
4.Whentheattachmentisfullysupported,lowerthelift
armuntiltheliftarmiscompletelydownontheloader
stops.
5.Rollthebucketorattachmentout,stoppingwiththe
bucketedgejustofftheground.
6.Turnofftheengine,unfastenseatbelt,raisethere-
straintbar,andexittheoperator’scompartment.
7.Pushthetwolatchhandles(1)downovercenterto
engagethelockpinsintotheretainingtabsonthe
attachmenttosecuretheattachmenttothecoupler.
931068974
WARNING
Fallingobjecthazard!
Beforeoperatingthemachine,alwaysmake
surethebucketorattachmentissecurely
lockedintothequick-attachplate.Aloader
bucketorattachmentthatisnotsecurely
lockedintothequick-attachplatecouldcome
offduringloaderoperation.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0166A
8.Raisetheattachmentandslowlyrollthebucketorat-
tachmentout.Makeavisualinspectionofthelockpins
(1)engagementintheattachmentlowertabslots.
•
Iftheattachmentisnotproperlysecuredtothecoupler,
lowertheliftarmandrepeatthemountingprocedure.
•
Beforeusingtheattachment,theoperatormustoperate
itthroughitsfullrangeofmotionandconrmthatthe
attachmentissecureandsafe.
860929265
Removingtheattachment
1.Lowertheattachmenttotheground,stoptheengine,
conrmthattheparkingbrakeissetandexittheskid
steer.
2.Pullthelatchinghandlesuptotheunlatchedposition
toreleasethepinsfromthelowerattachmenttabs.
NOTICE:Besurethelatchhandlesarefullyraised.
3.Fastenyourseatbelt,lowertherestraintbar,startthe
engine,andreleasetheparkbrake.
4.Tilttheattachmentforwardsothatthefrontedgeis
restingontheground.
5.Continuetiltingthecouplerforwardandbacktheskid
steerawayfromtheattachmentatthesametime.
