CASE CONSTRUCTION Alpha Series - Page 247

7-MAINTENANCE
Installation
RAIL17SSL0039BA9
1
Sliderglass
5
Fixedupperglass
2Frame6Lowerseals
3Latch
7
Lowerglass
4Frame
Lowerglass
1.Placetheglassintotheouterseal.
2.Startingatthefront,bottomcorner,pressthelowerseal
downintotheframeallthewaytotheback.
3.Startingatthefront,topcorner,presstheuppersealup
intotheframeallthewaytotheback.
4.Startingatthetop,pressthefrontsealintotheframe
allthewaydowntothebottomcorner.
Fixedupperglass
5.Placeglassbackintotheframeandslideintorearward
positionjustasitwasremoved.
6.PresstheouterPVCchanneldownintotheframeuntil
itsnapsinplace.
Sliderglass
7.Pressthefront,innerPVCchanneldownintotheframe,
slidingitforwardasfaraspossible.
8.Placethesliderglassintothetrackandpushforward
untillatched.
9.PressthefrontedgeofthelastPVCchanneldowninto
theframejustbehindthesliderglassuntilandpush
forwarduntilitmeetsthefrontPVCchannelunderneath
theglass.
10.Pressthechanneldownintotheframeworkingfrom
fronttobackuntilitsnapsintoplace.
7-83
