Pivotleverwindowstyle
Removal
1.Loosenthefourengagementknobsatbothendsofthe
window,untiltheyarebackedoutabout13mm(0.5in).
9310934010
2.Slidethefronttwoknobsandthereartwoknobstoward
thecenterofthewindowuntilthegreenindicatorhas
changedtored.Nowthewindowbarcandropdown
slightly,allowingthetopofthewindowtodropdown
justbelowthewindowframe.
NOTE:Therestraintbarmustbeintheoperatingposition
forwindowremoval.
93109336A11
3.Tiltthetopoftheforwardmostwindowinwardsoitcan
beliftedupandoutforproperwindowcleaning.
9310933812
4.Withtherearwindowremaining,itcanbepulledfor-
wardinthetrack,exposingthewindowawayfromthe
windowframe.Thentiltthewindowinandliftitupjust
liketherstwindowtoremove.
5.Oncebothupperwindowshavebeenremoved,the
lowerwindowframeandtrackwiththeengagement
knobscanbeliftedupandoffthetopofthelowerwin-
dow.
9310933713
