7-MAINTENANCE

6.Pickupandremovethelowerwindowforcleaning.

9310933914

Installation

1.Installthelowerwindow.

2.Pushthewindowframeandtrackwiththeengagement

knobsdownontopofthelowerwindow.

3.Installtherearwindowintheoutsidetrackandslideit

backintoplace.

4.Installthefrontwindow.

5.Pullthewindowframeandtrackwithengagement

knobsupandslidethetwofrontknobsandthetwo

rearknobsawayfromthecenteruntiltheindicator

turnsgreen.

6.Tightenthefourknobs.

93109336A15

NOTICE:DONOTchangethewindowpositionwithout

properlylockingthewindowlatch!ImproperuseWILLre-

sultinprematurewear.

931002268A16

7-85
