LARGERADIALFRAMEWHEELUNITS(SR220,SR250)
ITEM
COMPONENTMEASUREMENT
SR220SR250
R
Clearancecircleradiuswithouttool1400.0mm(55.1in)
SClearancecircleradiuswith1828.8mm(72.0in)DF
bucket
2122.0mm(83.5in)
SClearancecircleradiuswith1828.8mm(72.0in)LP
bucket
2215.0mm(87.2in)
SClearancecircleradiuswith1828.8mm(72.0in)LPE
bucket
2333.0mm(91.9in)
T
Clearancecircleradiusrear1789.0mm(70.4in)
V
Overthetirewidth1448.0mm(57.0in)
W
Overallwidth1768.0mm(69.6in)
Operatingweight3350kg(7385lb)3490kg(7694lb)
SAERatedOperatingCapacity(ROC)1000kg(2205lb)1135kg(2502lb)
Tippingload
2000kg(4409lb)2270kg(5004lb)
Counterweight(optional)136.0kg(299.8lb)
Cabsideglass(optional)21.3kg(47.0lb)
Cabglassdoor(optional)34.0kg(75.0lb)
CabLexandoor(optional)34.0kg(75.0lb)
Suspensionseat(optional)10.0kg(22.0lb)
NOTE:MeasurementsarebasedonSR220machineswith12x16.5tiresanda1829mm(72in)Dirt&Foundry
(DF)bucket.
NOTE:MeasurementsarebasedonSR250machineswith12x16.5tiresanda1829mm(72in)LowProle(LP)
bucket.
NOTE:ClearanceCircleRadius(R,S,T)valueswerecalculatedusinga50/50weightdistribution(centerpointof
counterrotationcenteredbetweentheaxles)andwiththebucketrestingatonground.
